Trailer & Asset GPS Tracker- BT47 Series

by Black Tiger GPS
Original price $99.00 - Original price $99.00
Original price
$99.00
$99.00 - $99.00
Current price $99.00
Small and powerful, the BT47 Series is one of the most versatile asset trackers on the market! Designed with the latest GPS technology and ruggedized materials this little beast allows you to track, monitor and control your high-value assets under extreme conditions and in remote places where power availability may be a challenge!

THE MOST VERSATILE TRAILER
& GPS ASSET TRACKER

See How Black Tiger BT 47 Series Asset Tracker Dominates

  • blacktiger
    competitors
  • Frequent location updates:
    Every 15 mins when asset is moving
    Once per day when asset is stationary with 24 hour heartbeat

  • BT47 can be used wireless or wired for power. Rechargeable when wired for power and has a 5Ah battery.

  • Easy install with brackets – Included with the device. Magnets – 4PK or 3M™ VHB Tape can also be used.

  • Free OTA firmware and software updates

  • Internal temperature sensor, 3-axis accelerometer and motion detector

  • Rugged IP66 rated can withstand harsh environments.

WHAT IS THE BT47 SERIES
TRAILER & ASSET GPS TRACKER FOR?

THE LITTLE BEAST OF THE JUNGLE

Black Tiger's Trailer and Asset Tracker enables you to track and monitor all types of trailers and equipment. When used wirelessly this little beast can last up to 1 year without power. Powered and Un-powered Assets

  • Powered and Un-powered Assets
  • Containers, Trailers & Chassis (wired installation)
  • Generators
  • Tower Lighting Traffic Boards
  • Farming Equipment and More

HOW THE BT47 TRAILER
& ASSET GPS TRACKER WORKS

files/BT_-_Cloud-Based_Geozones_2_FINAL.png
files/BT_-_Dashboard_FINAL.png
files/BT_-_Satellite_Live_Asset_View_FINAL.png
4G LTE CONNECTIVITY

Never throttled 4G LTE connectivity integrated into the BT47 Series asset tracker ensures the device communicates with your BT advanced Asset Tracking platform in real-time.

ADVANCED REPORTING

Data received from BT 47 Series device is compiled into easy to read and customizable reports that include:

  • Engine hour report
  • Asset awareness report
  • Trip summary report
  • Mileage report
  • Alert report
  • Events/scheduling report
  • Dwell and demurrage report and more
REAL-TIME ALERTS

Email and SMS alerts are sent to your dedicated list of contacts that include:

  • Geo-zone enter/exist events,
  • Motion start/stop alerts
  • Temperature out of range alert
  • Acceleration alert
  • Battery disconnect alert
  • Battery voltage alert and more

TRAILER & ASSET GPS TRACKER
BT47 SERIES TECH SPECS

Size & Weight

Dimensions: 5.13” X 2.72” X 1.61” (130.3 x 69.1 x 40.9 mm)
Weight: 0.55 lbs (249.5 g)

Ping Rates/Reporting Intervals

• Every 15 Minutes In Motion
• Once A Day When Stationary

Power Requirements

DC Power: DC 8-30 V (Rechargable when Wired for Power)
• 5 Ah Li-Ion battery

Cellular Specs: 4G LTE- AT&T

• AT&T 4G LTE CAT-1
• 3GPP Release 9
• LTE FDD Bands 2, 4, 5, 12

Physical Connections

• Optional I/O: 2 Digital Input & 3 ADC Inputs
• Operating Temperature: -22 °F to 158 °F (-30 °C to 70 °C)
• Multi-function Button: WiFi/BLE Pairing, device wake-up
• Serial Interface: UART
• Harness Connector: 8-pin circular bayonet

GPS Module

• Receiver Type: 72 Channel, Tracking Sensitivity: -165 dBm
• Accuracy +/- 2.5 CEP
• Certifications; FCC, PTCRP, IC
